주요사양
Function Range Accuracy

-.DC V ; 600mV/6V/60V/600V/1000V ;±(0.5%+1)
-.AC V ; 6V/60V/600V/750V ; ±(1.0%+3)

-.DC A ; 20mA/200mA/10A ;±(1.0%+1)
-.AC A ; 10A ; ±(3.0%+3)

-.Ohm ;800/8k/80k/800k/8M/80M Ohm ; ±(0.3%+5)

-.Capacitance; 1nF/10nF/100nF/1uF/10uF/100uF ;±(3.0%+5)

-.Freq.; 999.9/9.9999k/99.999k/999.99K/8.000MHz
80kHz~1000MHz ;±(0.02%+2)

-.Temperature -40°C~1372°C/-40°F~2502°F ; ±(1.0%+1°C)

-.Party Cycle ; 0.1%~99.9%

-.Signal Analyse;AC+DC&DC,AC+DC&AC,DC&AC,dBm&AC+DC,
dBm+AC,dBm&DC,dBm&Hz,AC+DC&Hz,AC&Hz,°C&°F

-.Pulse Widith Measure ;0.1ms~2000ms

-.LCD Display 80000,and Analog Bar Graph
-. Square Wave Output ;
1).Duty Cycl:1%~99%
2).Frequency: 0.5,1,2,5,10,60,24,74,63,100,151,51,
200,303.3,606.6,1250,1666.6,2500,5000

-.Peak Value Take; 1ms,Peak+,Peak-
-.Dynamic Record; MAX,AVG,MIN,MAX-MIN
